Superior Elector less Nickel plating is an alloy of 10-12% Phosphorus in Nickel as compared to conventional low content (less than 9%) of Phosphorus & having advantage of highly corrosion resistance coating. It is recommended where maximum corrosion protection is required. Salt Spray Resistance of 1000 Hours as per ASTMB 117 test can be achieved. There is absolutely no comparison of corrosion resistance property of Superior Electroless Nickel Plating with conventional low content of Phosphorus Electroless Nickel Plating.
Superior Electorless Nickel Plating is applied wherever a uniform, hard and highly corrosion resistance coating is required. Its high hardness and lack of porosity makes it an ideal coating for components to aggressive usage. The as-plated hardness of Superior Electroless Nickel Plating is in range of 46 to 48 HRc and can be heat treated to 66 to 70 HRc for a more wear resistance finish.
Because the coating is deposited ”CHEMICALLY” rather than with electricity, the problems normally associated with electroplating like edge built-up, uneven thickness and no plating in corners are avoided. Superior Electroless Nickel Plating deposits guarantee 100% coverage and are so uniform that the surface finish is normally duplicated and after plating, process kike machining and grinding is not required. Advantage of this uniformity is that threads and other complex shapes also maintain their original geometry after plating.
  1. Excellent corrosion resistance property.
  2. Excellent wear & abrasion resistance property.
  3. High hardness up to 70 HRc.
  4. Coating can be done on any base metal like M.S, C.I, Aluminum, EN Series, HCHCR, Copper, and Brass etc.
  5. No costly post treatment like machining and grinding required because of uniform thickness layer.
  6. Parts with complex shapes are coated since this process provides 100% coverage with no edge build up.
  7. Excellent adhesion.
  8. Low coefficient of friction.
AUTOMOTIVE PARTS BEARING CAMS
DIE TEXTILE PARTS ELECTRONICS PARTS
FOOD PROCESSING PARTS FOUNDRY PATTERNS GEARS
HEAT SINKS HYDRAULIC CYLINDERS PISTON ROADS
PLASTIC MOLDS PRINTING ROLLERS PUMP SLEEVE
ROTORS RUBBER MOLDS SHAFTS
SLIDES TAPPINGS TABLET PUNCHES
